Signature Louvre Window

Launch Gallery Signature Louvre Window
Overview

Statesman's Signature Louvre Window system incorporates Bradnam's 102mm or 152mm louvre gallery into our 125mm wide frame. Statesman's Louvre window is designed to allow full control over air flow and light, with easy to use operating handles and an integral fitted flyscreen inside the frame.

Features & Benefits

Signature Louvre Window

  • Maximum airlfow control
  • 102mm or 152mm blade option
  •  UV stabilised state-of-the-art polymer components
  • Cast alloy pivot bearings
  • 6mm toughened safety glass with polished edges
  • Standard manual control mechanism
  • Remote handle for hook rod, winch or motorised operation
  • Tested to meet AS4420 test methods & passed AS/NZS2047-2014
Performance Parameters

Signature Louvre Window

  • Frame Size 125mm
  • Maximum Height 2471mm (subject to design limitations)
  • Maximum Width 5430mm (subject to design limitations)
  • Maximum Panel Width 1000mm (subject to design limitations)
  • Maximum Water Rating 300pa
  • Maximum Wind Rating 4500Pa ULS
  • Maximum Acoustic Rating Rw23
  • Maximum Glass Thickness 6mm (single glazed)
  • Maximum Bushfire Attack Level BAL 19

Bradnam's Louvre Galleries

Please note: Frame colours are not limited to what is shown in this brochure. See our colour range for all available colours.

Actual gallery colours are limited to Satin Black, Pearl White and Ultra Silver (Grey)

Not all options in this brochure are available by Statesman Windows.

Please visit our showroom and speak with our sales team for more information.
